7 elements LFA Yagi for 144MHz spec.

Detail of Antenna (single)

Fre. range	2 m band (144 mhz)
Gain:	12.81 dBi
Type:	7 elements LFA Yagi
Max power:	100W
Impedance:	50 ohms
Dimensions:	Boom: 3m
Weight:	Less then 2 Kg
Swr	1 : 1.1 / 1 Mhz
F/Back Ratio	21.21 dB
Matching	N/A

7 elements LFA Yagi for 144MHz (4 stack)

I have done 4 sets last night .

and ready for tune the match.

This is my new antenna project for 2 meter. thanks to G0KSC.
and this is still under construction.

GlobalSET 2009/2 Freq & Stations

GlobalSET 2009
For more Information and photo , please visit JASRA and 9M2ZAK blog.

Setting up 2 elements 20 meter antenna for 9M2ODY

Everything is ready.

After I reached his house ,the first thing I have to do is take back my 3 elements 10meter yagi antenna. Click to see what I am doing on top of the roof !

The 4 elements 10meter yagi .

Assembled the 2 elements 20meter yagi before installation.

Bring down the pole and do some adjustment.

Tighten up the Boom to the pole.

Have a POSE with 9M2ODY , before we pull the guide wire.

Having a POSE again after everything was done ..haha...

Nice look !! huh ??

Solder up the PL259 socket.

Ready to connect ......

Hey!! ODY,where is my RIBENA ?
you better give me or I won`t let you .........hehehe...

On the second days , he QSO with A68 & W8 station with a RST 58.
And after a few days of OSQ ,He told me that how satisfied he was !!
Anyhow , I told him "We are HAM"

9M2GET Antenna Tower in Perlis

I have to call my mother and father to have a permission before go up ! hehe....

SO HIGH......80ft from ground !!!

Having some discuss with 9M2GET .

Full view of the Antenna tower.

More info and photo at 9M2GET and 9M2ZAK .

2 Elements 20 meter Yagi (for 9W2ZAK)

On 1/11/2009 Sunday , Two of us (me and 9W2zak) put this antenna up !!
with-in 1 hour ,every was done and ready for DXing !!

This antenna is the one I use at World JOTA 2009.
and now 9W2ZAK own it !

2 Elements 20 meter Yagi (for 9W2ODY ,under construction)

This is my 3rd 20meter homebrew antenna ,newer design ,lighter and shorter boom length,
idea for potable use . (1.7m boom length)

World JOTA

See how I bring these antenna with my 4x4 . hahaha...

This Loop Antenna for 2Meter station.

9w2zak bring his own Icom ic-718 for 20meter band .

9W2BDX

Thanks for helping !!

20meter band antenna setup.

Finally this 2 elements 20meter has been done and use on this event, And the result of this antenna is Very Good !! All the station get 59 report !!

4elements 10meter band antenna on this events .

9W2ZAK's Yeasu FT-77 for 10meter band.

Nice post ? Huh ??

9W2BDX was teaching students .....How to QSO ?

My own Yeasu FT-897D and Daiwa CNW-419II tuner for 40meter band with G5RV Antenna .

2 Elements 20 meter Yagi (under Testing)
